Specifications

Fuel Pump Type: Electric external

Flow Rate: 105 gph/397 lph

Fuel Pressure (psi): 90 psi

Fuel Pump Voltage: 12 V

Fuel Pressure Regulator Included: No

Sending Unit Included: No

Fuel Pump Inlet Size: -10 AN

Inlet Quantity: 1

Inlet Attachment: Female straight cut O-ring

Fuel Pump Outlet Size: -10 AN

Outlet Quantity: 1

Outlet Attachment: Female straight cut O-ring

Gasket Included: No

Wiring Harness Included: No

Mounting Bracket Included: No

Mounting Hardware Included: No

Pulley Included: No

Remanufactured: No

Quantity: Sold individually.

Notes: Not compatible with pulse modulated systems or fuel pump speed controllers.

Features

• Extended service life in ethanol and methanol
• Integral, external brushless controller for clean installation, cooler fuel, and enhanced reliability
• Inlet and outlet ORB-10 ports
• Requires straight 12 VDC to 16 VDC power supply (16 V charge systems require voltage regulator or step-down to 12 V)
• Not compatible with pulse modulated systems or fuel pump speed controllers
• Rated flow of 700 lbs./hr. at 45 psi, 13.5 volts for EFI engines
• Rated flow of 900 lbs./hr. at 9 psi, 13.5 volts for carbureted engines
• Fuel injected gas engines rated up to 1,300 HP naturally aspirated and up to 1,000 HP forced air induction
• Carbureted gas engines rated up to 1,500 HP naturally aspirated and up to 1,200 HP forced air induction
• Fuel injected E85 engines rated up to 910 HP naturally aspirated and up to 700 HP forced air induction
• Carbureted E85 engines rated up to 1,050 HP naturally aspirated and up to 840 HP forced air induction
• Ideal for blow-through carbureted engines up to 1,200 FWHP
